Arangodb, Install and Configure The Popular Database in Ubuntu 16.04

ArangoDB, install and configure the popular Database in ubuntu 16.04
by Janeth Kent Date: 14-11-2017 arangodb nosql sql ubuntu linux db

Introduction to ArangoDb, open source, NoSQL, multi-model database

BigData seems to be getting stronger every day and more and more NoSQL databases are coming out to the market, all trying to position themselves in the lead to be the reference. This week I tried ArangoDB! Another NoSQL database? Today I'm going to tell you what I thought of ArangoDB.

ArangoDB is an open source, NoSQL, multi-model database developed by triAGENS GmbH. It is a multi-purpose database with a flexible data model for documents, graphs, and key-values. It provides all the database features that are needed for a modern web application.

When working with documents, MongoDB, CouchBase or Cassandra seem to be at the forefront, there are other NoSQL database oriented to networks such as Neo4j or Horton. Maybe ArangoDB may not be as popular as these, but that doesn't mean it's worse. One thing that has caught my attention about this NoSQL database engine is that it combines the key values and graphs.

ArangoDB provides user-friendly, easy-to-use, graphical user interface and a CLI for system administration and system monitoring.

In this tutorial we will learn how to install and configure ArangoDB on Ubuntu 16.04.


  • A server running Ubuntu 16.04.
  • A non-root user with sudo privileges setup on your server.

Installing ArangoDB

Before starting, make sure your server is up-to-date. You can do this with the following commands:

sudo apt-get update -y
sudo apt-get upgrade -y

Next you will need to download the public key from the ArangoDB site to set up the ArangoDB repository.

Run the following command to download the public key:

curl -O

Now add the key with the following command:

sudo apt-key add - < Release.key

Next add the ArangoDB repository to sources.list and update the system again:

echo 'deb /' | sudo tee /etc/apt/sources.list.d/arangodb.list
sudo apt-get install apt-transport-https
sudo apt-get update

Now install ArangoDB with the following command:

sudo apt-get install arangodb3=3.2.6

Once installation is complete, verify the status with the following command:

sudo systemctl status arangodb

You should see the following output:

● arangodb3.service - LSB: arangodb
   Loaded: loaded (/etc/init.d/arangodb3; bad; vendor preset: enabled)
   Active: active (running) since Tue 2016-11-01 13:27:55 IST; 15s ago
     Docs: man:systemd-sysv-generator(8)
    CGroup: /system.slice/arangodb3.service
           ├─2676 /usr/sbin/arangod --uid arangodb --gid arangodb --pid-file /var/run/arangodb/ --temp.path /var/tmp/arangod --log.foregro
           └─2677 /usr/sbin/arangod --uid arangodb --gid arangodb --pid-file /var/run/arangodb/ --temp.path /var/tmp/arangod --log.foregro

Nov 01 13:27:50 Node1 systemd[1]: Starting LSB: arangodb...
Nov 01 13:27:50 Node1 arangodb3[2611]:  * Starting arango database server arangod
Nov 01 13:27:55 Node1 arangodb3[2611]: {startup} starting up in daemon mode
Nov 01 13:27:55 Node1 arangodb3[2611]:    ...done.
Nov 01 13:27:55 Node1 systemd[1]: Started LSB: arangodb.
Nov 01 13:27:55 Node1 arangodb3[2611]: changed working directory for child process to '/var/tmp'

Accessing ArangoDB Shell

ArangoDB comes with arangosh that provides a command line shell to access the database. You can create new databases, users, collections, documents, and perform all administrative tasks using this client.

You can launch ArangoDB command line interface by running the following command:


At the password prompt, enter your root password, you should see the following output:

Please specify a password:

  __ _ _ __ __ _ _ __   __ _  ___  ___| |__
 / _` | '__/ _` | '_ \ / _` |/ _ \/ __| '_ \
| (_| | | | (_| | | | | (_| | (_) \__ \ | | |
 \__,_|_|  \__,_|_| |_|\__, |\___/|___/_| |_|

arangosh (ArangoDB 3.0.10 [linux] 64bit, using VPack 0.1.30, ICU 54.1, V8, OpenSSL 1.0.2g-fips  1 Mar 2016)
Copyright (c) ArangoDB GmbH

Pretty printing values.
Connected to ArangoDB 'http+tcp://' version: 3.0.10 [server], database: '_system', username: 'root'

Type 'tutorial' for a tutorial or 'help' to see common examples[email protected]_system>

If you want to get any help, run the following command:[email protected]_system>db._help();

Working with ArangoDB

You can also create your own database and add a user to it.

For example, create a user with name user1 and password password with the following command:[email protected]_system> require("org/arangodb/users").save("user1", "password");
  "user" : "user1",
"active" : true,
"extra" : {
  "changePassword" : false,
  "code" : 201

By default users will not have permissions to access any databases, you will need to grant access rights to it.

Lets give 'user1' permissions to access the _system() DB:[email protected]_system> require("org/arangodb/users").grantDatabase("user1","_system");

You can also revoke the access to a database for a user with the following command:[email protected]_system> require("org/arangodb/users").revokeDatabase("user1","_system");

If you want to change an existing ArangoDB user's password, run the following command:[email protected]_system> require("org/arangodb/users").update("user1", "new_password");
  "user" : "user1",
  "active" : true,
 "extra" : {
  "changePassword" : false,
  "code" : 200

To list out all the existing users of the database, run the following command:[email protected]_system> require("org/arangodb/users").all();

To remove user1 from database, run the following command:[email protected]_system> require("org/arangodb/users").remove("user1");

ArangoDB Web Interface

ArangoDB comes with built-in, user friendly web interface for performing administrative tasks.

You will need to make some changes in the ArangoDB configuration files in order to access web interface.

Open the arangod.conf file located in the /etc/arangodb3/ directory:

sudo nano /etc/arangodb3/arangod.conf

Change the following line with IP address of your server:

endpoint = tcp://

Next, open the arangosh.conf file located at /etc/arangodb3/ directory:

sudo nano /etc/arangodb3/arangosh.conf

Change the following line with IP address of your server:

endpoint = tcp://
authentication = true

Once you are finished restart the arangodb service:

sudo systemctl restart arangodb3

Open your favourite web browser and type the URL http://your-server-ip:8529. This will open up the login screen for the _system db as shown below:

ArangoDB Login Screen

Login using your username and password. You should see a screen like this:

ArangoDB Splash Screen


You have successfully installed the ArangoDB database on your server. You can now easily deploy ArangoDB in a production or development environment. ArangoDB is a powerful database with a wide range of features. It has very good documentation if you want to learn more.
