Memcache: Installation and Usage On Ubuntu 12.10

Memcache: Installation and Usage on Ubuntu 12.10
by Janeth Kent Date: 03-05-2013 cache memcache mysql ubuntu


About Memcache


Memcache is a system that works to speed up virtual private servers by caching server information. The program allows you to allocate a specific amount of the server ram toward caching recently queried data for a certain amount of time. Once the data is requested again, memcache speeds up the process of retrieving it by displaying the cached information instead of generating the result from the database.

Setup

The steps in this tutorial require the user to have root privileges.

Before starting off, it's a good idea to update apt-get to make sure that all of the packages we download to the VPS are up to date.
sudo apt-get update

Additionally, you should have MySQL and PHP installed on the virtual server.
sudo apt-get install mysql-server php5-mysql php5 php5-memcache

Install Memcache


Installing memcache takes several steps.

To start, install memcached via apt-get.
sudo apt-get install memcached

The next step is to install php-pear, the repository that stores memcache.
sudo apt-get install php-pear

If you do not have a compiler on your server, you can download build-essential in order to install memcache:
sudo apt-get install build-essential

Finally use PECL (PHP Extension Community Library) to install memcache:
sudo pecl install memcache

Say yes by pressing enter during the installation when you are asked if you would like to “Enable memcache session handler support? [yes] :”

Once you have completed the installation of memcache with PECL on the VPS, add memcached to memcache.ini:
sudo echo "extension=memcache.so" > sudo /etc/php5/conf.d/memcache.ini

Now you are ready to start using Memcache.

Confirm Memcache and See Stats


After Memcache is downloaded, you can check that it has been installed by searching for it:
ps aux | grep memcache

Additionally, you can see the memcache stats by typing:
 echo "stats settings" | nc localhost 11211

Step Three—How Memcache Works


Memcache works by redirecting code to first attempt to retrieve data from the cache before querying the server’s database. The cache populates by saving recently retrieved server data for a certain amount of time. By caching recently requested information, future queries do not have to go through the longer process of retrieving the information from a database and can, instead, access it through the cache.

The memcache page shows this abbreviated code on its homepage to summarize the memcache process:
function get_foo(foo_id)
    foo = memcached_get("foo:" . foo_id)
    return foo if defined foo

    foo = fetch_foo_from_database(foo_id)
    memcached_set("foo:" . foo_id, foo)
    return foo
end

A Simple Memcache Example


This section will set up a simple php script to use memcache for retrieving a single value originally found in a mysql table.

The following steps set up a mysql user who can access the appropriate database, create a table to query, and insert the one value that we will test in the new mysql table.

Log into mysql: mysql -u root -p and execute the following commands:

use test;

grant all on test.* to [email protected] identified by 'testing123';

create table example (id int, name varchar(30));

insert into example values (1, "new_data");

exit;

Once you have exited MySQL, create the memcache script file:
nano memtest.php

We are now going to build up the php script step by step (the entire script will be at the end of the section):

  • Start off by creating a new persistent connection with memcache, which runs on memcache’s default port, 11211.
    <?php
    $meminstance = new Memcache();
    $meminstance->pconnect('localhost', 11211);

  • The next step is to connect to the new mysql database with the user that we created earlier:
    mysql_connect("localhost", "test", "testing123") or die(mysql_error());
    mysql_select_db("test") or die(mysql_error());

  • After that, go ahead and create the query that we will pose to the server, as well as provide a key to identify that specific action:
    $query = "select id from example where name = 'new_data'";
    $querykey = "KEY" . md5($query);

  • The script first searches the cache for the answer to the query. If the result does not exist, the script reroutes the question to the original database. Once the query has been answered by the original database, the script stores the result in memcache, using the “set” command-- which both saves it and allows the user to designate the number of seconds that it should remain in the cache (600 would save it in the cache for 10 minutes).

    When we run the script for the first time, it will inform us that the data was collected from the mysql database. However, as it does so, it stores the information in the cache, so that a second run of the script retrieves it from the cache and lets the user know.

    In 10 minutes the cache is emptied once more and running the script will make it access the database once again.

    $result = $meminstance->get($querykey);

    if (!$result) {
           $result = mysql_fetch_array(mysql_query("select id from example where name = 'new_data'")) or die('mysql error');
           $meminstance->set($querykey, $result, 0, 600);
    print "got result from mysql\n";
    return 0;
    }

    print "got result from memcached\n";
    return 0;

    ?>

Altogether the script looks like this:
<?php
$meminstance = new Memcache();
$meminstance->pconnect('localhost', 11211);

mysql_connect("localhost", "test", "testing123") or die(mysql_error());
mysql_select_db("test") or die(mysql_error());

$query = "select id from example where name = 'new_data'";
$querykey = "KEY" . md5($query);

$result = $meminstance->get($querykey);

if (!$result) {
       $result = mysql_fetch_array(mysql_query("select id from example where name = 'new_data'")) or die('mysql error');
       $meminstance->set($querykey, $result, 0, 600);
print "got result from mysql\n";
return 0;
}

print "got result from memcached\n";
return 0;

?>

Running the script on the command line produces the following results:
# php memtest.php
got result from mysql

# php memtest.php
got result from memcached

# php memtest.php
got result from memcached

Conclusion


This tutorial covers speeding up the retrieval of data from a database by connecting it to memcache. However, do keep in mind that memcache’s strengh originates from the fact that is a cache—it is not a datastore. When using memcache, do not expect it to replace a database. Because memcache only holds values for a set length of time for a given key, you may not always find the information you need cached, and in cases like these, having the original server database is imperative.

Nevertheless, memcache is a very useful program and can do a lot to increase the server efficiency.
